2-Axis / 4-Gimbal Airborne Electro Optical Targeting System For Surveillance And Prewarning

2-Axis / 4-Gimbal Airborne Electro Optical Targeting System For Surveillance And Prewarning

    • 2-Axis / 4-Gimbal Airborne Electro Optical Targeting System For Surveillance And Prewarning
    • 2-Axis / 4-Gimbal Airborne Electro Optical Targeting System For Surveillance And Prewarning
    • 2-Axis / 4-Gimbal Airborne Electro Optical Targeting System For Surveillance And Prewarning
  • 2-Axis / 4-Gimbal Airborne Electro Optical Targeting System For Surveillance And Prewarning

    Product Details:

    Place of Origin: CHINA
    Brand Name: JOHO
    Certification: ISO9001:2000
    Model Number: D330

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: negotiation
    Packaging Details: Standard Safety Equipment Case
    Delivery Time: 2months after received payment
    Payment Terms: T/T, L/C, D/P
    Supply Ability: 100Sets/Year
    Contact Now
    Detailed Product Description
    Technology: Infrared Style: Gimbal
    Sensor: MWIR Cooled Thermal Camera Sensor Size: 640X512
    Kind: Continuous Zoom Applications: UAV And Manned Aircraft Target Monitoring
    Configuration: Thermal Camera,Continuous Zoom TV Camera And Laser Rangefinder Standard: GJB
    Feature: Waterproof,weatherproof Certification: ISO9001:2000 SGS
    Effective Distance: 6km Function: Search, Detect And Tracking Target

    2-Axis / 4-Gimbal Airborne Electro Optical Targeting System For Surveillance And Prewarning





    2-Axis and 4-Gimbal Airborne Electro Optical E/O IR Thermal Targeting Pod System is equipped with a

    high performance MWIR cooled thermal camera (640×512 resolution) and day light camera for day

     and night surveillance. Using 2-axis and 4-gimbal mechanism, built-in high precision gyro,

     its stabilization accuracy is up to 30μrad. Easy operation, user is able to independently complete all operation.



    2-Axis and 4-Gimbal Airborne Electro Optical E/O IR Thermal Targeting Pod System is suitable

     for various search, observation,tracking,  law enforcement and evidence collection.



    APPLICAITON
    Maritime surveillance ship, coast guard,  fishery administration ship



    TECHNICAL SPECIFICATION

    Thermal camera

    Detector

    MWIR Cooled FPA StirlingCooling

    Pixel

    640×512

    Detection range

    ≥4Km (3m×6m lifeboat)

    Recognition distance

    ≥1.5Km (3m×6m lifeboat)

    Day light camera

    Sensor

    color CCD

    Resolution

    ≥400TVL(720×576)

    Detection range

    ≥6Km (3m×6m lifeboat)

    Recognition distance

    ≥4Km (3m×6m lifeboat)

    Gyro stabilization

    Stabilization accuracy

    ≤30μrad

    Detection scope


    Azimuth: 360°×n continually
    Elevation: +110°~-20°(straight down is 0°)

    Physical

    Dimension

    330mm×510mm (H)

    Weight

    ≤32Kg

    2-Axis / 4-Gimbal Airborne Electro Optical Targeting System For Surveillance And Prewarning
