Airborne Electro Optical Infrared Tracking System , Electro Optical Surveillance System

Airborne Electro Optical Infrared Tracking System , Electro Optical Surveillance System

    • Airborne Electro Optical Infrared Tracking System , Electro Optical Surveillance System
    • Airborne Electro Optical Infrared Tracking System , Electro Optical Surveillance System
  • Airborne Electro Optical Infrared Tracking System , Electro Optical Surveillance System

    Product Details:

    Place of Origin: CHINA
    Brand Name: JOHO
    Certification: ISO9001:2000
    Model Number: JH260

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: negotiation
    Packaging Details: Safety Box
    Delivery Time: 2-3months after received payment
    Payment Terms: T/T, L/C,
    Supply Ability: 200Sets/Year
    Contact Now
    Detailed Product Description
    Technology: Infrared Style: Pod
    Type: Multi Sensor EO IR Camera Sensor: MWIR Cooled HgCdTe FPA
    HDMI Format: PAL/NTSC Sensor Size: 320x256
    Effective Distance: 8km Applications: Border Patrol, Piracy Surveillance
    Configuration: Thermal Camera,Day Light Camera,laser Range Finder Standard: GJB / MIL-STD

    Airborne Electro Optical Infrared Tracking System , Electro Optical Surveillance System





    Airborne Electro Optical Infrared Tracking System with Thermal Imaging Camera Day Light Camera and Laser Range Finder





    Description:



    JH260 Airborne Electro Optical Infrared Tracking System  is an outstanding light-weight electro
    optical surveillance
    system for helicopter, UAV, vessel, vehicle and any carriers. Through manual or auto

    model, it is capable of detection and tracking air, sea and ground targets, provides target azimuth and

    elevation angle data, as well as optional distance data to terminal device. It had been widely applied in

    day & night navigation, forest fire alarm, border petrol, piracy surveillance, terrain survey, power line

    inspection.





    Function

    •  Target detection, recognition and localization
    •  Output image video signal
    •  Target capture and tracking
    •  Output LOS (line of sight) angle
    •  Built in self-test


    Specifications:



    THERMAL CAMERA

    Pixel

    320×256 Cooled FPA

    Spectral l Range

    3μm~5μm

    FOV

    WFOV: 8°×6°    NFOV: 2°×1.5°

    DAY LIGHT CAMERA

    Spectral l Range

    0.4μm~0.7μm

    FOV

    24°×18°~2.4°×1.8° continuous zoom

    LASER RANGE FINDER

    Spectral l Range

    1.54μm

    Measuring Range

    300m~8000m

    Range Error

    5m

    PAN TILT

    Pan

    360° continuous

    Tilt

    -110°~+30°

    Dimension

    ≤Φ 260mm×400mm

    Weight

    ≤18Kg (Including elevating system)



    Airborne Electro Optical Infrared Tracking System , Electro Optical Surveillance System
