20Km Dual FOV Cooled Thermal Security Camera With Compact Design

20Km Dual FOV Cooled Thermal Security Camera With Compact Design

  • 20Km Dual FOV Cooled Thermal Security Camera With Compact Design
  • 20Km Dual FOV Cooled Thermal Security Camera With Compact Design
  • 20Km Dual FOV Cooled Thermal Security Camera With Compact Design
20Km Dual FOV Cooled Thermal Security Camera With Compact Design
Product Details:
Place of Origin: CHINA
Brand Name: JOHO
Certification: ISO9001:2000
Model Number: JH320-300/75
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Customized Aluminum Alloy Case
Delivery Time: 2-3months after received payment
Payment Terms: T/T
Supply Ability: 50Sets/Year
Contact Now
Detailed Product Description
Features: Waterproof,compact Design Detector: Cooled HgCdTe FPA
Pixel: 320x256 (optional: 640×512) Spectral Range: 3.7μm~4.8μm
Cooling Type: Stirling Cycle Cooling Focal Length: 300mm/75mm
Command and Control Interface: RS232 / RS422 Pan Range: 360°×n Continuous
Power Supply: 24VDC~36VDC Applications: Search And Rescue
Operating Temperature: -40ºC~+60ºC Electronic Zoom: ×2
High Light:

20Km Thermal Security Camera

,

Rugged Design Cooled Thermal Security Camera

,

2 FOV Cooled Thermal Security Camera

20Km Dual-FOV CooledThermal Security Camera


Dual-FOV cooled thermal security camera series includes a series of matured and high reliability product with military standard. Built on high sensitivity 3rd generation 320x256 cooled FPA detector with 300mm / 75mm dual-FOV lens, it achieves the mission of fast situational awareness and target recognition with wonderful wide and narrow field of view in one camera. Besides,It adopts the advanced image processing algorithms which greatly enhances the image quality and camera performance under special environment.

Features

  • Switchable 2-FOV optics satisfies multi-mission and fast searching and accurate locating
  • Intelligent image enhancement optimizes the image quality

  • Standard mechanical interface for easy integration

  • Waterproof, compact and rugged design

Applications

     ◆ Border/Coastal security surveillance and monitoring

     ◆ EO IR system integration

     ◆ Search and rescue

     ◆ Airport, bus station, sea port, dock monitoring

     ◆ Forest fire prevention



Technical Specification

System Parameters
Pan range 360°×n continuous
Tilt range ±80°
Pan speed 0.1~30°/s Max.
Tilt speed 0.1~25°/s Max.
Communication and control RS422 / Ethernet
Shield Yes, heating, air-cooled, sunshade, wiper
Thermal Camera
Detection range
(visibility: 23km,
15m×10m target)
10km 20km
Sensor Uncooled FPA VOx Cooled FPA HgCdTe
Pixel 320×240, 17μm×17μm 320×256, 30μm×30μm
Spectral band 8μm~12μm 3μm~5μm
NETD ≤55mK ≤35mK
Frame frequency 25Hz 50Hz
Focus length 150mm/75mm 300mm/75mm
FOV 2°×1.5°/ 4°×3° 1.8°×1.5°/ 7.3°×5.8°/
Focusing Motorized
Electronic zoom ×2
Image Processing DDE (Digital Detail Enhancement),
ACG (Automatic Gain Control)
Daylight Camera
Recognition range
(visibility: 23km,
15m×10m target)
10km 20km
Sensor 1/3" color CMOS 1/3" color CMOS
Pixel 1024×768 1024×768
Color Black/white Black/white
FOV 0.9°×0.7°~37°×27.5° 18°×13.5°~1°×0.75°
Continuous zoom yes
Focusing Motorized, auto focus
Automatic light control Yes
Communication Interface RS422
Video output 1-way PAL
Image Presentation
Video output PAL both thermal and visible channel
Environment parameters
Operating temperature -40ºC~+60ºC
Storage temperature -50ºC~+70ºC
IP Protection IP66, resist to corrosion, tarnishing, salt fog
Power Parameters
Power supply 24VDC~36VDC
Physical Parameter
Weight ≤40kg ≤50kg
Dimension Undetermined
Color White
Application Environment Outdoor
