Uncooled Infrared LWIR Thermal Imaging Camera Module Miniature Size 384×288

Miniature Size 384×288 Uncooled Infrared LWIR Thermal Imaging Camera Module


Features

• Suit long-range, multi-task search and observation
• Miniature size and light weight
• High sensitivity and high resolution
• Standard interface , easy to integrate
• Entire enclosure shell protection and compact design

Technical Specification

Model	UWA384CX-H09-F
Type	VOx Uncooled Infrared LWIR
Array format	384×288, 25μm
Spectral response	8~14μm
Power consumption	≤1.7W@25℃
Power supply	DC 6.5V~13V
Time to image	≤20s
Operating temperature range	－40℃~+60℃
Storage temperature rage	－55℃~+70℃
NETD (@1/f. 25Hz)	40mK
Focus motor driver	PWM adjustment
Video output	2 channel Analog video output, PAL formats
Communication interface	RS422
Main control function	Manual background calibration, Manual shutter calibration, Polarity setting, 1×~2× continuous zooming, Cross cursor display, Cross cursor position adjustment, Gain adjustment, Brightness adjustment, Digital Details Enhancement (DDE), Motorized focusing, Reticle display settings, System parameter reset
Five type reticle
Size	46mm×48.9mm×42mm
Weight	≤90g

Company Profile
Wuhan JOHO Technology Co., Ltd founded in 2009, is a high-technology company based on infrared thermal imaging technology. Joho has built a complete infrared industrial chain from the bottom up: from core component to comprehensive electro optical infrared surveillance and tracking system.We have two R & D base in Hubei Zhongxiang and Wuhan City, well-known institutions of higher learning and research institutions at home and abroad.





Customer Distribution

Service Process

Products
Our products includes thermal security cameras, electro-optics/infrared search and track system (EO/IR search and track system) and EO surveillance system, surveillance radar, laser range finder, fiber optical gyro, special power sources (thermal battery and silver-zinc battery Ag-zn battery) and OEM solutions,Personalized products and services to provide customers with a significant advantage. Due to the high quality of our products and reliable performance, Joho products are widely used in different applications, security and surveillance, law enforcement, maritime patrol, fishery administration, surveying and mapping and so on.
